Inverter Huawei 17kW SUN2000-17KTL-M2, Grid-type

Three-phase inverter Huawei 17kW SUN2000-17KTL-M2, Grid inverter

The Huawei SUN2000-17KTL-M2 inverter is a three-phase grid-tie inverter with a rated power of 17 kW, designed to efficiently convert solar energy into electricity. It supports a maximum input voltage of 1080 V and an operating voltage range of 160 V to 950 V, making it compatible with various photovoltaic systems. The inverter has two MPPT trackers, enabling optimal tracking of the maximum power point and increasing system efficiency.

With a maximum efficiency of 98.65% and a European weighted efficiency of 98.30%, this inverter provides high performance and reliability. Its compact dimensions (525 x 470 x 262 mm) and weight of 25 kg facilitate installation and integration into various solar installations. The inverter is equipped with natural convection for cooling, which reduces the need for maintenance and increases its reliability.

Advantages of Huawei 17kW SUN2000-17KTL-M2 inverter

One of the main advantages of this inverter is the active protection against electric arc, managed by artificial intelligence, which reduces the risk of fire and increases the safety of the system. The possibility of using optimizers allows the installation of more modules on the roof and up to 30% more energy production by optimizing each photovoltaic module. The absence of quick-wear components and the low failure rate (<0.5%) guarantee long service life and reliability.

Additional features and applications

The Huawei SUN2000-17KTL-M2 inverter supports communication via RS485 and optional WLAN/Ethernet via Smart Dongle, which facilitates system monitoring and management. With an IP65 protection rating, the inverter is dust and water resistant, making it suitable for outdoor installation. The wide operating temperature range of -25°C to +60°C and the ability to operate at altitudes up to 4000 m make it suitable for various climatic conditions and environments.

Smart

• 2 MPP trackers for the most flexible system possible – different modules, different slopes, shaded areas, etc.
• 4 strings – intelligent monitoring and quick detection of the problem
• RS485 and USB ports for quick connection to the inverter
• Export Limitation option (requires electricity meter) – limiting the return of excess energy to the grid
• Built-in online monitoring through the Fusion Solar platform

Huawei provides advanced photovoltaic technology manufactured for direct use, especially in the small scale of residential, commercial and local power plants. Enables ongoing optimization from construction through operation to maintenance. The integration of digital information and Internet technology is a guarantee for optimizing initial investments, reducing operation and maintenance costs, increasing energy efficiency and a more favorable return on investment.
Huawei’s flagship product in the field of advanced residential and commercial photovoltaic technology is FusionSolar. It consists of Huawei photovoltaic converters, optimization tools, protection devices, current sensors and external communication modules. To monitor and manage the operation of the photovoltaic plant, the FusionSolar applications and the intelligent FusionSolar control system are available to the operators. The SUN2000APP application and Web UI internet software help to handle the installation and commissioning of the solar inverters and other Huawei technologies.
