Hybrid inverter Deye SUN 10kW – SG02LP1-EU-AM3, single-phase
Original price was: 2147,43 €.1790,00 €Current price is: 1790,00 €. VAT included(≈ 3,500.94 лева)
The Deye SUN-10K-SG02LP1-EU-AM3 single-phase hybrid inverter is a durable and reliable product designed for use in solar systems.
Main features of Deye SUN-10K-SG02LP1-EU-AM3 inverter
Power and purpose
The Deye SUN-10K-SG02LP1-EU-AM3 single-phase hybrid inverter is a highly efficient 10kW device designed to convert direct current (DC) generated by photovoltaic panels into alternating current (AC), which can be used to power household appliances, office equipment or other electrical consumers.
This inverter is a flexible solution for energy independence as it can operate in both on-grid and off-grid modes. Thanks to the built-in hybrid technology, it allows energy storage in batteries, providing backup power in the event of a power outage.
Deye SUN-10K-SG02LP1-EU-AM3 features an intelligent control system that optimizes the use of solar energy, reduces grid dependence, and improves energy efficiency. Its system supports parallel operation with up to 16 inverters, making it suitable for larger installations.
Additionally, the inverter is equipped with a modern LCD touch display, which provides convenient control and monitoring of operating parameters in real time. With IP65 protection, the device is resistant to external influences, making it suitable for installation both indoors and outdoors.
Main features of the hybrid inverter Deye SUN 10kW – SG02LP1
- Color touch LCD display – easy to manage interface
- IP65 protection level – high resistance to external influences
- AC pair – allows upgrading an existing solar system
- Maximum charge/discharge current: 250A
- Six battery charge/discharge time periods
- Compatibility with diesel generators – energy storage capability
- Parallel operation support – up to 16 inverters for online and offline work
- Support for multiple parallel batteries
- Remote shutdown function
- Smart monitoring platform
Intelligent management and monitoring
The inverter has smart remote monitoring platform, which allows:
- Automatic shutdown in emergency situations
- Remote update of parameters and firmware (FW)
- Optimized support of the photovoltaic system
Warranty and conditions
The warranty period of the inverter is 5 or 10 years, depending on the installation location.
Deye Group was established in 2000. The company provides a full range of photovoltaic power generation solutions, including residential and commercial power plant solutions, as well as providing solar energy storage system solutions. The company currently has three production bases in Beilun and Cixi, Ningbo, covering an area of 388 acres and a production area of over 400,000 square meters, and its production value will exceed RMB 13 billion in 2023. Ningbo Deye Energy Storage Technology Co., Ltd., as a subsidiary of Deye, is committed to creating better energy storage products for the world and becoming the world’s leading energy storage system provider.
| Weight | 35,6 kg |
|---|---|
| Power | |
| inverter type | Hybrid Inverters |
| Тип | Single phase |
| manufacturer | |
| Инвертори - Low & High Voltage | Low Voltage |
Specifications
Battery type – Lead-acid or Lithium-ion
Battery Voltage Range (V) – 40-60
Max. Charging current (A) – 220
Max. Discharge current (A) – 220
Li-ion battery charging strategy – Self-adaptation to BMS
Number of battery inputs – 1
Max. PV input power (W) – 13000
Max. PV input voltage (V) – 500
Пусково напрежение (V) – 125
MPPT Обхват на напрежение (V) – 150-425
Nominal PV input voltage (V) – 370
Max. Operating PV input current (A) – 26+26+26
Max. Input short circuit current (A) – 44+44+44
Number of MPP trackers/Number of MPP tracker strings – 3/2+2+2
Rated AC input/output active power (W) – 10000
Max. AC input/output apparent power (VA) – 11000
Rated AC input/output current (A) – 45.5/43.5
Max. AC input/output current (A) – 50/47.9
Max. Continuous AC pass (charging grid) (A) – 60
Peak power (off-grid) (W) – 2 times the rated power, 10s
Power factor adjustment range – 0.8 leading to 0.8 lagging
Rated Input/Output Voltage/Range (V) – 220/230 0.85Un-1.1Un
Nominal input/output frequency/network range (Hz) – 50/45-55, 60/55-65
Form for connecting to the network – L+N+PE
Total harmonic distortion of current THDi – <3% (from rated power) DC injection current – <0,5% In Max. Efficiency – 97,6%
MPPT Efficiency – >99%
Communication interface – WIFI, RS485, CAN
Operating temperature range (℃) – -40 до +60℃, >45℃ Reduction
Noise (dB) – <45 Ingress Protection Rating (IP) – IP65
Inverter topology – non-isolated
Cabinet size (WxHxD mm) – 420×670×233 (Without connectors and brackets)
Weight (kg) – 35.6 kg
Warranty – 5 years/10 years – the warranty period depends on the final installation location of the inverter, more information please see the Warranty Policy
Documentation
Technical Characteristics – EN
User manual – EN
List of approved batteries – EN
Technical Characteristics – BG
User manual – BG
List of approved batteries – BG
