EPEVER Tracer AN G3 10-40A MPPT Controller
65,16 € - 90,60 €(≈ 127.44 лева)
SKU: N/A
Categories: MPPT, Controllers
Tags: controller, Tracer, solar controller, AN, G3, MPPT, 20A, 30A, 40A, 10a
EPEVER Tracer AN G3 10-40A MPPT Solar Controller
The EPEVER Tracer AN G3 10-40A MPPT controller is a new generation of solar controller with high efficiency and extended compatibility. Thanks to the advanced MPPT technology, it guarantees maximum energy extraction from photovoltaic panels even in low light conditions. This makes it suitable for both home and professional solar systems.
The device supports various battery types, including LiFePO₄, and provides stable operation at temperatures up to +50°C. Built-in protections, LCD display and communication capabilities via RS485 make Tracer AN G3 a reliable and easy-to-configure component in any installation.
Main advantages of the Tracer AN G3 MPPT solar controller
The controller offers many improvements over the previous generation. It works with a wider range of batteries, including modern lithium models. Temperature resistance up to +50°C makes it a reliable choice for hot climates.
The USB port allows for direct powering of mobile devices. In addition, the new LCD display is more readable and provides clear information about the system’s operation. The controller consumes less current in idle mode – only 10mA, which is important for autonomous systems.
Technical reliability and convenience in one with the Epever Tracer controller
EPEVER Tracer AN G3 has an improved IP rating – IP33. This means better protection against dust and moisture. Combined with the multiple built-in protections – from short circuit to reverse connection – the controller guarantees safe and long-lasting operation.
With a Modbus interface and remote monitoring capability, the device is perfect for smart solar solutions. This makes it an excellent choice for anyone looking for a flexible and modern MPPT controller.
EpEver products come with a 2-year warranty that covers manufacturing defects and ensures reliability and quality throughout the warranty period.
EPEVER is a well-established global manufacturer of solar controllers, inverters and energy solutions, known for reliability, high efficiency and innovation. Founded in 2007, the company offers products with global certifications (CE, ROHS, ISO9001) and a presence in over 120 countries, making it the preferred choice for solar systems of all sizes.
| Weight | N/A |
|---|---|
| Power | 10A, 20A, 30A, 40A |
Specifications
Nominal battery voltage - 12/24VDC Automatic detection
Nominal charging current - 10A
Nominal discharge current - 10A
Controller operating voltage range - 8~31V
PV Maximum open circuit voltage - 60V
MPPT voltage range - (battery voltage +2V)~36V
Rated charging power:
130W/12V
260W/24V
Static losses:
≤8mA (12V)
≤5mA (24V)
Voltage drop in the discharge circuit - ≤0.23V
Temperature compensation - -3mV/℃/2V (default)
Grounding Type - Common Negative
RS485 port - 5VDC/200mA (RJ45)
LCD Backlight Time - Default: 60S, Range: 0~999S (0 seconds: backlight is ON all the time)
Operating temperature range - -25℃~+45℃(100% load working)
Storage temperature range - -20℃~+70℃
Relative humidity - < 95% (N.C.)
Degree of protection - IP30
Size (L x W x H) - 172x139x44 mm
Weight - 0.57 kg
Nominal battery voltage - 12/24VDC Automatic detection
Nominal charging current - 20A
Nominal discharge current - 20A
Controller operating voltage range - 8~31V
PV Maximum open circuit voltage - 60V
MPPT voltage range - (battery voltage +2V)~36V
Rated charging power:
260W/12V
520W/24V
Static losses:
≤8mA (12V)
≤5mA (24V)
Voltage drop in the discharge circuit - ≤0.23V
Temperature compensation - -3mV/℃/2V (default)
Grounding Type - Common Negative
RS485 port - 5VDC/200mA (RJ45)
LCD Backlight Time - Default: 60S, Range: 0~999S (0 seconds: backlight is ON all the time)
Operating temperature range - -25℃~+45℃(100% load working)
Storage temperature range - -20℃~+70℃
Relative humidity - < 95% (N.C.)
Degree of protection - IP30
Размер (Д x Ш x В) - 220x154x52 мм
Weight - 0.94 kg
Nominal battery voltage - 12/24VDC Automatic detection
Nominal charging current - 30A
Nominal discharge current - 30A
Controller operating voltage range - 8~31V
PV Maximum open circuit voltage - 100V
MPPT voltage range - (battery voltage +2V)~72V
Rated charging power:
390W/12V
780W/24V
Static losses:
≤8mA (12V)
≤5mA (24V)
Voltage drop in the discharge circuit - ≤0.23V
Temperature compensation - -3mV/℃/2V (default)
Grounding Type - Common Negative
RS485 port - 5VDC/200mA (RJ45)
LCD Backlight Time - Default: 60S, Range: 0~999S (0 seconds: backlight is ON all the time)
Operating temperature range - -25℃~+45℃(100% load working)
Storage temperature range - -20℃~+70℃
Relative humidity - < 95% (N.C.)
Degree of protection - IP30
Size (L x W x H) - 228x164x55 mm
Weight - 1.26 kg
Nominal battery voltage - 12/24VDC Automatic detection
Nominal charging current - 40A
Nominal discharge current - 40A
Controller operating voltage range - 8~31V
PV Maximum open circuit voltage - 100V
MPPT voltage range - (battery voltage +2V)~72V
Rated charging power:
520W/12V
1040W/24V
Static losses:
≤8mA (12V)
≤5mA (24V)
Voltage drop in the discharge circuit - ≤0.23V
Temperature compensation - -3mV/℃/2V (default)
Grounding Type - Common Negative
RS485 port - 5VDC/200mA (RJ45)
LCD Backlight Time - Default: 60S, Range: 0~999S (0 seconds: backlight is ON all the time)
Operating temperature range - -25℃~+45℃(100% load working)
Storage temperature range - -20℃~+70℃
Relative humidity - < 95% (N.C.)
Degree of protection - IP30
Size (L x W x H) - 252x180x63 mm
Weight - 1.65 kg
